2.5 "Group Monitor" Application
2-11
CBM-20A/20Alite
2
2.5.2 "Status Summary" Section
The "Status Summary" section consists of the following three tab pages.
• "Status" tab page
• "System Check" tab page
• "Maintenance" tab page
All pages are accessible by clicking the tabs. The "Status" tab page remains visible when
accessing via the Web server.
 "Status" Tab Page
Display item Description
System Name
(Click to Login)
Name of the system configured with the system controller. Click on
the icon or the system name to display the "Login" window for that
system.
Status
Displays a summary of the information displayed in the "Analysis"
tab page for the system.
"Status Display" P. 2-19
Analyst Displays the name of the user registered for the current analysis.
Column/Comments
Displays the column-oven information read by the CMD (Column
Management Device) that is connected to the column oven. The
mobile phase name that was specified in the screen used for
setting the mobile phase reserve volume is also displayed. The
column name and size are displayed in the upper field and the
mobile-phase name is displayed in the lower field. If a CMD is not
connected to the column oven, the comments for the current
analysis method are displayed.
"Status" Tab Page
1
2
3
4
5
6
7
8
1
2
3
4
