1.3 Optional Parts
Optional units available for this instrument are listed below.
For information about other optional units not listed below, contact your Shimadzu
representative
 Optional Boards
 Optical Cables
• Each LC-30A/20A/LC-10Avp/LC-10A-series component comes with a 1m optical cable for
use in connecting to the system controller. The 2 m optical cables (not included) may be
used in place of the 1 m optical cables. Do not use an optical cable that is longer than 2 m.
• To connect the system controller to the Chromatopac, use one of the optical cables
described in the above table. It is also possible to use an RS-232C cable instead of an
optical cable.
Part Part No. Remark
CBM-OPT4 Optical-connector
Expansion Board
S228-45652-48 For optical-connector expansion (CBM-20A only)
PC-55N A/D Board
S223-03507-91
S228-35327-91
A/D conversion board used when connected to
the LC Workstation (CBM-20A only)
Part Part No. Remark
Optical cable, 1 m S070-92025-51
Optical cable, 2 m S070-92025-52
Optical cable, 3 m S070-92025-53
Optical cable, 5 m S070-92025-54
