Shimadzu CBM-20A User Manual

5.12 Parameter Details
5-109
CBM-20A/20Alite
5
5.12.5 Fraction Collector
 Method Parameters for the Fraction Collector
 FRC-10A
Parameter Setting range Minimum unit Default setting Remark
Standard Rack1
Start Vial No. -1, 0 to 143 1 0 Start Vial No.  End Vial No.
End Vial No. -1, 0 to 143 1 143
Standard Rack2
Start Vial No. -1, 0 to 63 1 0 Start Vial No. 
End Vial No.
End Vial No. -1, 0 to 63 1 63
Standard Rack3
Start Vial No. -1, 0 to 15 1 0 Start Vial No. 
End Vial No.
End Vial No. -1, 0 to 15 1 15
Standard Rack4
Start Vial No. -1, 0 to 49 1 0 Start Vial No. 
End Vial No.
End Vial No. -1, 0 to 49 1 49
Standard Rack5
Start Vial No. 0 0 Set 0 for [Start Vial No.]
End Vial No. 120 120 Set 120 for [End Vial No.]
User Racks 6 to 8
Start Vial No.
-1, 0 to
(See note 1.)
1 (See note 1.) Start Vial No. 
End Vial No.
End Vial No.
-1, 0 to
(See note 1.)
1 (See note 1.)
User Racks9
Start Vial No. 0 0 Set 0 for [Start Vial No.]
End Vial No. (See note 2.) (See note 2.)
Common parameters
Slope (µV/sec) 0 to 1000000 1 100
Level (µV)
-4500 to
1000000
1 -4500
Width (sec) 1 to 99 1 10
Auto Delay On, Off On
Flow Rate (mL/min)
0.100 to
150.000
0.001 1.000
Detector Time Constant
(sec)
0.00 to 20.00 0.01 1.00
