117
8012428/YWL2/3-0/2016-08| SICK O P E R A T I N G I N S T R U C T I O N S | DUSTHUNTER T
Subject to change without notice
SPECIFICATIONS 7
7.3.2 Reflector
Fig. 81: Reflector DHT-R5x
7.3.3 Reflector DHT-R0x, DHT-R1x
128
116
Ø 100
Ø 126
Ø 80
Ø 25
Designation
Part No.
Reflector DHT-R50
1029495
Reflector DHT-R51
1029715
Reflector DHT-R52
1040169
Designation
Part No.
Reflector DHT-R00
1043905
Reflector DHT-R10
1043906
Reflector DHT-R01
1043907
Reflector DHT-R11
1043908
Reflector DHT-R02
1044093
Reflector DHT-R12
1044244
Reflector DHT-R13 (for active measuring paths up to 50 m)
1046009
341
240
205
140
207
r
=
2
3
4
214
∅ 40
