8012428/YWL2/3-0/2016-08| SICK O P E R A T I N G I N S T R U C T I O N S | DUSTHUNTER T
Subject to change without notice
START-UP AND PARAMETER SETTINGS 4
4.5.2 Setting the Ethernet module parameters
Standard setting: 192.168.0.10
A predefined IP address is set on request.
To change the settings:
▸ Select directory “Configuration / I/O Configuration / Interface Module”.
▸ Set the desired network configuration in the “Expansion module information” field and
click “Reset module”.
Fig. 57: SOPAS ET menu: MCU/Configuration/IO configuration/Interface Module
NOTICE:
The risk of undesired access to the measuring system is inherent when communicating
via Ethernet.
▸ Operate the measuring system only behind suitable protection (e.g., Firewall).
The configuration of interface module Ethernet type 2 (see “Options for MCU control
unit”, page 125) is not possible with program SOPAS ET. A special software with descrip-
tion is supplied with the program.
