6 Other Functions
32
6.1 Operation Menu
The operation menu allows such functions as measure range, purge start, and rolling average
reset.
1. Press the [MENU] key in the MEAS. screen.
The OPERATION menu appears on the MENU 1/5 screen.
Fig. 26 MENU 1/5 (OPERATION menu) screen
2. Press the button for the item to be set. The setting screen appears or the operation
is performed.
Pressing each button allows the corresponding operations as follows:
3. When the setting screen is displayed, change the setting and press the [SET] key.
Change the setting in each setting screen, and press the [EXIT] key.
The screen returns to the MENU 1/5 (OPERATION menu) screen.
4. Press the [EXIT] key in the MENU 1/5 (OPERATION menu) screen.
The screen returns to the MEAS. screen.
* Functions of “PURGE START”, “ROLLING AVERAGE RESET”
are optional.
MEASURE RANGE Displays the MEAS. RANG screen (page 33 Fig. 27).
PURGE START
(optional)
Optional function; not displayed in the standard specification.
For the operation procedure, refer to " 10.1.3 Purge start " (page 99).
ROLLING AVERAGE
RESET
(optional)
Optional function; not displayed in the standard specification.
For the operation procedure, refer to " 10.3.1 Rolling average time set "
(page 106).
