2 PRODUCT DESCRIPTION
2.2.4 MCU control unit
Control unit MCU has the following functions:
● Control of the data traffic and processing of the sender/receiver unit data connected via
the RS485 interface
● Signal output via analog output (measured value) and relay outputs (device status)
● Signal input via analog and digital inputs
● Power supply for the connected measuring unit via 24 V switch-mode power supply with
wide range input
● Communication with higher level control systems via optional modules
Equipment and device parameters can be set easily and conveniently via a USB interface
using a PC and a user-friendly operating program. The parameters are stored reliably even
in the case of a power failure.
Control unit MCU has a sheet steel enclosure as standard.
2.2.4.1 Standard interfaces
Analog output Analog inputs Relay outputs Digital inputs Communication
0/2/4...22 mA
(electrically isolated,
active); resolution
10 bits
● 1x on DUSTHUNTER
T50
● 3x on DUSTHUNTER
T100/200
2 inputs 0 ... 20 mA
(standard, without
electrical isolation);
Resolution 10 bits
5 changeover contacts
(48 VAC, 1 A) to output
status signals:
● Operation/failure
● Maintenance
● Function check
● Maintenance request
● Limit value
4 inputs to connect
potential-free contacts
(e.g. to connect a
maintenance switch,
trigger a function
check or further error
messages)
● USB 1.1 and
RS232 (on termi-
nals) for measured
value inquiries, set-
ting parameters
and software
updates.
● RS485 for sensor
connection
