SICK DUSTHUNTER T100 User Manual

52
8012428/YWL2/3-0/2016-08| SICKO P E R A T I N G I N S T R U C T I O N S | DUSTHUNTER T
Subject to change without notice
3 ASSEMBLY AND INSTALLATION
3.3.4.3 Connection of connection line to MCU
Fig. 30: Plug connector connection to onsite line
Cable provided by customer according to
page 47, §3.3.2
Closed
Closed
Open
Open
A
A
A -A

+24 V
Note
To open, connect the plug connector to the plug
on the sender/receiver unit.


RS485 B

RS485 A


gnd

Shield
