2 PRODUCT DESCRIPTION
2.3 Device features and configuration
2.3.1 Device features
The DUSTHUNTER T measuring system is available in three different device versions with
the following features:
Feature
Device version
DUSTHUNTER T50 DUSTHUNTER T100 DUSTHUNTER T200
Active measuring
path
0.5...2.5/2...5/4...8 m 0.5...2.5/2...5/4...12 m
Smallest measuring
range
● Transmission 100...50%
● Opacity 0...50%
● Extinction 0...0.3
● Transmission 100...80%
● Opacity 0...20%
● Extinction 0...0.1
● Transmission 100...90%
● Opacity 0...10%
● Extinction 0...0.045
Measurement
uncertainty
±0.8% transmission ±0.4% transmission ±0.2% transmission
Swivel error (at
±0.3°)
1% transmission 0.8% transmission 0.2% transmission
Contamination
measurement
Without
On one side with pivoted
shutter in sender/
receiver unit
On both sides with
pivoted shutter
Limit values (trans-
mission)
None
20% for warning
30% for failure
30% for warning
40% for failure
Self-alignment None With
Display (on MCU) Option Standard
Analog output 1 3 (2x with module)
Analog input 2
Digital input 4
Relay outputs 5
