4 START-UP AND PARAMETER SETTINGS
4.4.2 Factory settings
*: Only when an optional analog module is present (standard on DUSTHUNTER T100 and T200)
The steps required to modify these settings are described in the following Sections. For this
purpose, the devices must be connected in SOPAS ET (see “Connection to the device via
USB line”, page 58), the Level 1 password set and the “Maintenance” mode set.
Parameter Value
Function check Every 8 h; output of control values (every 90 s)
on standard analog output
Analog output (AO)
[mA]
Live zero (LZ) 4
Upper measuring range value
(MBE)
20
Current during maintenance 0.5
Current by malfunction 21 (optional 1)
Response time 60 s for all measured variables
Measured variable
Output on AO Value at LZ Value at MBE
Transmission [%]
100 0
Opacity [%]
1 0 100
Extinction
3 * 0 2
Dust concentration [mg/m³]
2 * 0 200
Regression coefficients (only for dust concentration) 0.00 / 1.00 / 0.00
