8012428/YWL2/3-0/2016-08| SICK O P E R A T I N G I N S T R U C T I O N S | DUSTHUNTER T
Subject to change without notice
ASSEMBLY AND INSTALLATION 3
Version with integrated wide-range power pack:
● Connect the 2-wire cable (twisted pair, with shield) to the connections for RS485 A/B
and shield in the control and remote control unit.
● Connect the 3-wire power cable with sufficient cross-section to the onsite power supply
and the corresponding terminals in the remote unit.
3.3.6 Connecting the reflector on DUSTHUNTER T200
Connect the cable belonging to this component (see “Line sender/receiver unit - reflector”,
page 124) to the sender/receiver unit and reflector and screw tight.
NOTICE:
During installation, it must be possible to switch the power supply off
using a power isolating switch/circuit breaker in accordance with EN
61010-1.
After completion of the work or for test purposes, the power supply may
only be activated again by the personnel who carried out the work and
complying with the valid safety regulations.
