6 Other Functions
35
6.2 Maintenance/Data Menu
The maintenance/data menu allows such checks as analog input value, analog output value,
calibration coefficient history, alarm history and CO peak count (optional).
1. Press the [MENU] key in the MEAS. screen.
Press the [X] key once to display the MENU 2/5 (MAINTENANCE/DATA menu)
screen.
Fig. 29 MENU 2/5 (MAINTENANCE/DATA menu) screen
2. Press the button of the item to be set.
Pressing each button allows the corresponding operations as follows:
3. Confirm the situation and press the [EXIT] key in each screen.
The screen returns to the MENU 2/5 (MAINTENANCE/DATA menu) screen.
Tip
To cancel the change, press the [CANCEL] key. The change is canceled and the screen returns to the
MENU 2/5 (MAINTENANCE/DATA menu) screen.
4. Press the [EXIT] key in the MENU 2/5 (MAINTENANCE/DATA menu) screen.
The screen returns to the MEAS. screen.
* Function of “CO PEAK COUNT” is optional.
ANALOG INPUT Displays the ANALOG INPUT screen (page 36 Fig. 30).
ANALOG OUTPUT Displays the ANALOG OUTPUT screen (page 38 Fig. 32).
CAL. ADJUSTMENT
HISTORY
Displays the CALIBRATION HISTORY screen (page 39 Fig. 33).
ALARM HISTORY Displays the ALARM HISTORY screen (page 40 Fig. 35).
CO PEAK COUNT
(optional)
Displays the CO PEAK COUNT screen (page 41 Fig. 36).
This is an optional function and not displayed in the standard
specification.
It is also displayed when the CO PEAK COUNT is set to ON (refer to
page 116).
