Display Output level Possible cause Rectification of the error
Ü
No level change Restart delay is counting
do
wn
b
N
o action is required
On the universal I/
O
4)
Not an error
Ð
On the universal I/
O
5)
Optics cover is contami‐
nated, operation is not guar‐
anteed
b
Cle
an the optics cover.
Ñ
On the universal I/
O
6)
Optics cover is contami‐
nated, operation is still guar‐
anteed
b
Cle
an the optics cover.
1)
If warning field 1 is interrupted.
2)
If this is configured as the output for warning field 2 and warning field 2 is interrupted.
3)
If this is configured as the output for “Reset required”.
4)
If this is configured as the output for a contamination error/warning.
5)
If this is configured as the output for a contamination error.
6)
If this is configured as the output for a contamination warning.
Table 25: Error and status indications of the LEDs on the S300 Mini Remote
Display Possible cause Rectification of the error
Ë
Device in operation Not an error
Ê
Error
Is no
t used for OSSDs in the OFF state as
per current standards (S300 Mini Remote
does not have OSSDs).
Depending on the cause of the
error (see table 26, page 102)
É
Object in one of the warning fields Not an error
Ð
Optics cover is dirty, operation is not guar‐
ant
eed
b
Cle
an the optics cover.
Ñ
Optics cover is dirty, operation is still guar‐
ant
eed
b
Cle
an the optics cover.
Further topics
"St
atus indicators", page 17
"Pin assignment", page 65
10.3 Error and status indications on the 7segment display
This section explains the meaning of the error and status indications of the 7-segment
dis
play and how you can respond.
Table 26: Error and status indications on the 7segment display
Display Possible cause Remedy
, , , ,
, , ,
Power-up cycle - all seg‐
ment
s are activated con‐
secutively.
Not an error
Object in the protective
field
Not an error
Object in warning field 1 Not an error
Object in warning field 2 Not an error
10 TROUBLESHOOTING
102
O P E R A T I N G I N S T R U C T I O N S | S300 Mini 8014170/ZA23/2019-11-14 | SICK
Subject to change without notice
