SICK S300 Mini User Manual

Minimum Typical Maximum
Optics cover
Material Polycarbonate
Interface Outside with scratch-resistant coating
Device dimensions
Height 116 mm
Width 102 mm
Depth 105 mm
Connecting cable dimensions
Length 250 mm
Round plug connector diameter 15 mm
Total weight (without connecting cables) 0.8 kg
1)
For detailed information on the safety configuration of the machine/system, please consult your SICK
sub
sidiary.
Functional information
T
able 28: Functional information
Minimum Typical Maximum
Resolution of the S300 Mini Short Range 30 mm, 40 mm, 50 mm, 70 mm
Protective field of the S300 Mini Short Range
At 30 mm resolution 1.00 m
At 40 mm resolution 1.00 m
At 50 mm resolution 1.00 m
At 70 mm resolution 1.00 m
Resolution of the S300 Mini Medium Range 30 mm, 40 mm, 50 mm, 70 mm
Protective field of the S300 Mini Medium Range
At 30 mm resolution 1.25 m
At 40 mm resolution 1.60 m
At 50 mm resolution 2.00 m
At 70 mm resolution 2.00 m
Resolution of the S300 Mini Long Range 30 mm, 40 mm, 50 mm, 70 mm,
150 mm
Protective field of the S300 Mini Long Range
At 30 mm resolution 1.25 m
At 40 mm resolution 1.60 m
At 50 mm resolution 2.10 m
At 70 mm resolution 3.00 m
At 150 mm resolution 3.00 m
Scanning angle 270°
Radiance factor 1.8% Several
1,000%
(r
eflectors
1)
)
Angular resolution 0.5°
Generally necessary protective field supplement 100 mm
TECHNICAL DATA 12
8014170/ZA23/2019-11-14 | SICK O P E R A T I N G I N S T R U C T I O N S | S300 Mini
109
Subject to change without notice
