Page #110 background imageLoading...
Page #110 background image
Minimum Typical Maximum
Supplement for retro-reflectors on scan plane with
dis
tance of less than 1 m to protective field bound‐
ary
200 mm
Flatness of the scan field at 2 m ± 50 mm
Distance of mirror rotational axis (zero point of X-
and Y-axis) to rear side of device
55 mm
Distance between center point of scan plane and
bottom edge of the housing
80 mm
Warning field
2)
8 m
Distance measurement range 30 m
Number of multiple samplings (can be configured
v
ia CDS)
2 16
Power-up delay of a configured device 18 s
Restart after (can be configured) 2 s 60 s
Basic response time
3)
80 ms
1)
Complies with Diamond Grade 3000X™ (approx. 1,250 cd/lx × m²).
2)
The detection capability of the warning field depends on the radiance factor of the objects to be detected
(see "Char
acteristic curves", page 113).
3)
The total response time of the application depends on further factors (see "Response times", page 115).
Electric
T
able 29: Electric
Minimum Typical Maximum
Supply voltage (SELV)
1)
2)
16.8 V 24 V 30 V
Permissible residual ripple
3)
± 5%
Start-up current
4)
2.0 A
Operating current without output load
5)
S300 Mini Standard 0.16 A 0.20 A
S300 Mini Remote 0.14 A 0.20 A
S300 Mini Standard Long Range 0.18 A 0.25 A
S300 Mini Remote Long Range 0.16 A 0.22 A
Operating current with maximum output load
5)
S300 Mini Standard 1.35 A
S300 Mini Remote 0.22 A
S300 Mini Standard Long Range 1.35 A
S300 Mini Remote Long Range 0.24 A
Power consumption without output load
5)
S300 Mini Standard 3.9 W 4.8 W
S300 Mini Remote 3.4 W 4.8 W
S300 Mini Standard Long Range 4.4 W 6.0 W
S300 Mini Remote Long Range 3.9 W 5.3 W
Power consumption with maximum output load
5)
S300 Mini Standard 33 W
S300 Mini Remote 5.3 W
S300 Mini Standard Long Range 33 W
S300 Mini Remote Long Range 5.8 W
12 TECHNICAL DATA
110
O P E R A T I N G I N S T R U C T I O N S | S300 Mini 8014170/ZA23/2019-11-14 | SICK
Subject to change without notice
