Minimum Typical Maximum
Power consumption in standby mode or park mode without output load
5)
S300 Mini Standard 3.6 W 4.8 W
S300 Mini Remote 3.6 W 4.8 W
S300 Mini Standard Long Range 4.4 W 6.0 W
S300 Mini Remote Long Range 3.9 W 5.3 W
Electrical connection Connecting cable with round plug connec‐
t
or
Cable length for power supply tolerance ± 10% 25 m
Cable length for power supply tolerance ± 5% 34 m
Cable length for power supply tolerance ± 1% 40 m
Universal I/Os and output for warning field 1
Input resistance at HIGH 2 kΩ
Voltage for HIGH 11 V 24 V 30 V
Voltage for LOW –3 V 0 V 5 V
Input capacitance 15 nF
Static input current 6 mA 15 mA
Actuating time of the control switch for restart 120 ms 200 ms
Switching voltage HIGH at 100 mA U
V
– 3.3 V U
V
Source switching current 100 mA 200 mA
Current limiting (after 5 ms at 25 °C) 600 mA 920 mA
Power up delay 1.4 ms 2 ms
Switch off delay 0.7 ms 2 ms
Response time
Out
put for warning field 1
Universal I/O with configuration as output for
warning field 2
Corresponds to the resulting response
t
ime of the OSSDs plus 50 ms
OSSDs (S300 Mini Standard only)
Output signal switching device pair 2 PNP semiconductors, short-circuit pro‐
t
ected
6)
, cross-circuit monitored
Safe status when a fault occurs At least one OSSD is in the OFF state.
Switching voltage HIGH at 250 mA U
V
– 2.7 V U
V
Switching voltage LOW 0 V 0 V 2 V
Source switching current
7)
6 mA 250 mA
Leakage current
8)
250 µA
Load inductance 2.2 H
Load capacity 2.2 µF at
50
Ω
Switching sequence (without switchover) 5 ¹/s
Permissible cable resistance
9)
2.5 Ω
Test pulse width
10)
230 µs 300 µs
Test frequency 120 ms
Power-up delay of the OSSDs from red to green 120 ms
Time offset on switching the OSSDs between
O
SSD2 and OSSD1
2 ms
Configuration and diagnostic interface
TECHNICAL DATA 12
8014170/ZA23/2019-11-14 | SICK O P E R A T I N G I N S T R U C T I O N S | S300 Mini
