Page #85 background imageLoading...
Page #85 background image
Important information
DANGER
In t
he case of non-compliance, it is possible that the dangerous state of the machine
may not be stopped or not stopped in a timely manner.
The minimum distance to the hazardous area depends on the monitoring situation.
b
Make sure that the minimum distance to the hazardous area is maintained for
each monitoring case.
Configurable monitoring cases
T
he number of monitoring cases that can be configured depends on the variant. The
following table shows the number of monitoring cases:
Table 18: Number of monitoring cases per variant and application
Standard Remote
Applications with static control inputs via EFI (e.g., on a Flexi Soft)
32
Applications with dynamic control inputs via EFI
32
Complementary information
Y
ou can configure the monitoring cases in the CDS.
Each monitoring case includes the following information:
The input conditions, the so-called control signals that control the activation of the
monitoring case.
A field set comprising a protective field and warning field(s).
If necessary, a unique follow-on case or two alternative follow-on cases.
The multiple sampling for the field set.
Monitoring cases can be switched with the following input information:
Static information
Speed information
A combination of the two
Further topics
"Mount
ing", page 58
7.11.1 Monitoring case switching via static input information
Overview
F
or monitoring case switching via static input information, you configure for each moni‐
toring case the input condition to be used to switch to this monitoring case.
CONFIGURATION 7
8014170/ZA23/2019-11-14 | SICK O P E R A T I N G I N S T R U C T I O N S | S300 Mini
85
Subject to change without notice
