Siemens FUS1010 User Manual

Appendix
A.2 I/O Connections and Wiring
FUS1010 IP65 NEMA 4X & IP66 NEMA 7
198 Operating Instructions, 01/2013, A5E02951520-AC
Table A- 15 Input/Output Wiring TB1 7ME39404SB00 - Analog Input Module (2 Chan/Dual Path)
Pin Color Function Description Wiring/Cable
TB1-1 Black RTD Current High
TB1-2 White RTD Voltage High
TB1-3 Green RTD Voltage Low
TB1-4 Red RTD Current Low
TB1-5 Blue Ground
RTD Temperature measurement T1 or
Channel 1 Ts (Supply Temperature)
AWG. 14 - 24 /
1000 Ft max w/o
factory approval
Table A- 16 Input/Output Wiring TB2 7ME39404SB00 - Analog Input Module (2 Chan/Dual Path)
Pin Color Function Description Wiring/Cable
TB2-1 Black RTD Current High
TB2-2 White RTD Voltage High
TB2-3 Green RTD Voltage Low
TB2-4 Red RTD Current Low
TB2-5 Blue Ground
RTD Temperature measurement T2 or
Channel 1 Tr (Return Temperature)
AWG. 14 - 24 /
1000 Ft max w/o
factory approval
Table A- 17 Input/Output Wiring TB3 7ME39404SB00 - Analog Input Module (2 Chan/Dual Path)
Pin Color Function Description Wiring/Cable
TB3-1 Black RTD Current High
TB3-2 White RTD Voltage High
TB3-3 Green RTD Voltage Low
TB3-4 Red RTD Current Low
TB3-5 Blue Ground
RTD Temperature measurement T3 or
Channel 2 Ts (Supply Temperature)
AWG. 14 - 24 /
1000 Ft max w/o
factory approval
Table A- 18 Input/Output Wiring TB4 7ME39404SB00 - Analog Input Module (2 Chan/Dual Path)
Pin Color Function Description Wiring/Cable
TB4-1 Black RTD Current High
TB4-2 White RTD Voltage High
TB4-3 Green RTD Voltage Low
TB4-4 Red RTD Current Low
TB4-5 Blue Ground
RTD Temperature measurement T4 or
Channel 2 Tr (Return Temperature)
AWG. 14 - 24 /
1000 Ft max w/o
factory approval
