Siemens MAG 5000 User Manual

70
SITRANS F M
8. Commissioning
)ORZUDWH
6HUYLFH
PRGH
/RZIORZ
&XWRII
([FLWDWLRQ
2Q
2Q
2II
&XUUHQWRXWSXW
&XUUHQWRXWSXW
1RUPDO
1RUPDO
)RUFHG
'LJLWDORXWSXW
1RUPDO
1RUPDO
)RUFHG
'LJLWDORXWSXW
5HOD\RXWSXW
1RUPDO
1RUPDO
)RUFHGRQ
)RUFHGRII
5HOD\RXWSXW
2SHUDWLQJ
WLPH[[[[GD\V
(UURUSHQGLQJ
6WDWXVORJ
/RJ[[[G[[K[[P
/RJ
3HQGLQJ[[[G[[K[[P
3HQGLQJ
&XUUHQWRXWSXW
)RUFHGP$
'LJLWDORXWSXW
)RUFHG+]
'LJLWDORXWSXW
)RUFHG+LJK
+LJK
/RZ
8.4.8
Service mode
All previous settings are reinitialized when service mode is exited using the top up key .
The error system
The error system is divided into an error pending list and a status log list. Time is gained as days,
minutes and hours since the error has occurred.
The first 9 standing errors are stored in error pending. When an error is removed it is removed from
error pending.
The latest 9 errors are stored in the status log. When an error is removed it is still kept in status log.
Errors in status log is stored for 180 days.
Error pending and status log are accessible when enabled in the operator menu.
Menu detail

Siemens MAG 5000 Specifications

General

Type	Electromagnetic Flowmeter
Protection Class	IP67
Material	Stainless Steel, Carbon Steel
Power Supply	24 V DC, 100-240 V AC
Accuracy	±0.2% of flow rate
Communication	HART, PROFIBUS, Modbus
Enclosure Rating	IP67
Ambient Temperature Range	-20°C to +60°C
Sizes	DN 2 to DN 3000
Lining Materials	PTFE, Hard Rubber
Electrode Materials	Stainless Steel, Hastelloy, Tantalum
Process Temperature	-40 to +180 °C (-40 to +356 °F) depending on liner
Process Pressure	Up to 40 bar (580 psi)
Approvals	ATEX, FM, CSA, IECEx
Flow Velocity Range	0 to 12 m/s
Output Signals	4-20 mA, Pulse, Frequency
