Modbus Register Types
The MultiRanger was designed to make it easy for master devices to get useful
information via Modbus. This chart gives an overview of the different sections. A more
detailed explanation of each section follows below.
Word Order (R40,062)
This determines the format of unsigned, double-register integers (UINT32).
• 0 indicates that the most significant word (MSW) is given first
• 1 indicates that the least significant word (LSW) is given first
See
Unsigned Double Precision Integer (UINT32)
on page 107 for more information.
Map ID (R40,063)
This value identifies the register map used by the MultiRanger. See
P782 Parameter Index
Location
on page 96.
See also
Parameter Access (R43,998 – R46,999)
on page 102 for details.
Type Description Start
#R
1
1.
Maximum registers shown; fewer may be used depending on options installed.
Data Type
Read/
Write
Point
Data
Temperature (2) 41,030
2
–50 to 150 R
Totalizer for points 1
and 2 [MR 200]
41,040
4
UINT32 R/W
I/O
Discrete Inputs (2) 41,070
1
Bit Mapped R
Relay Outputs (3 or
6)
41,080
1
Bit Mapped R/W
mA Input (1)
[MR 200]
41,090
1
0000 to
20,000
R
mA Output (2) 41,110
2
0000 to
20,000
R/W
Pump
Control
Pump on Setpoint (3
or 6)
41,420
6
0000 to
10,000
R/W
Pump off Setpoint (3
or 6)
41,430
6
0000 to
10,000
R/W
Pumped Volume (2)
[MR 200]
41,440
4
UINT32 R
Pump Hours (3 or 6) 41,450
12
UINT32 R
Pump Starts (3 or 6) 41,470
6
0000 to
10,000
R
Parameter Access 43,998 to 46999 R/W
Note: Additional information is available from our Web site at www.siemens.com/
processautomation
