Page 140 MultiRanger 100/200 – INSTRUCTION MANUAL 7ML19981FB05
mmmmm
Parameters
P122 Pump Service Ratio [MR 200]
Selects pump usage based on the RUN time ratio rather than last used.
This parameter only relates to relays with P111 = 54 or 55.
To make this parameter useful, assign it to all of the pump relays. The number assigned to
each pump relay represents the ratio applied to decide the next pump to start or stop.
Independent Relay Failsafe (P129)
P129 Relay Failsafe
Sets the failsafe operation per relay to allow for more flexible programming.
Use this for operations independent of the Failsafe Material Level (P070).
Primary Index Relay
Values
Range: 0.000 to 9999
Preset: 20.00
Related • P111 Relay Control Function
Primary Index Relay
Values
OFF * Response governed by P071 Failsafe Material Level
HOLd For LAST KNOWN relay state retention
dE To have the relay de-energize immediately on failsafe
En To have the relay energize immediately on failsafe
Altered by • P071 Failsafe Material Level
• P070 Failsafe Timer
• P111 Relay Control Function
Notes:
• All pump control relay ON and OFF setpoints must be the same value
• If the level is within 5% of Span (P007) of the OFF setpoint, the next pump is not
started
Notes:
• The MultiRanger will not sacrifice other pumping strategies to ensure that the ratio
is held true
• If the pump relays are set to the same value then the ratio equals 1:1 and all pumps
are used equally (preset)

Siemens MAG 5000 Specifications

General

Type	Electromagnetic Flowmeter
Protection Class	IP67
Material	Stainless Steel, Carbon Steel
Power Supply	24 V DC, 100-240 V AC
Accuracy	±0.2% of flow rate
Communication	HART, PROFIBUS, Modbus
Enclosure Rating	IP67
Ambient Temperature Range	-20°C to +60°C
Sizes	DN 2 to DN 3000
Lining Materials	PTFE, Hard Rubber
Electrode Materials	Stainless Steel, Hastelloy, Tantalum
Process Temperature	-40 to +180 °C (-40 to +356 °F) depending on liner
Process Pressure	Up to 40 bar (580 psi)
Approvals	ATEX, FM, CSA, IECEx
Flow Velocity Range	0 to 12 m/s
Output Signals	4-20 mA, Pulse, Frequency
