Parameters
P320 Flow Max [MR 200]
View the highest flow rate calculated (in units or %).
P321 Flow Min [MR 200]
View the lowest flow rate calculated (in units or %).
LCD Totalizer (P322 and P323) [MR 200]
Please note that these parameters apply to the MultiRanger 200 only.
Use these features to view, reset, or preset the eight-digit display totalizer when
Operation is set for OCM or Pumped Volume (P001 = 6 or 7). The eight-digit totalizer is
divided into two groups of four digits. The four least significant totalizer digits are stored
in P322, and the four most significant digits are stored in P323. Adjust these values
separately to set a new total.
Example
P323 = 0017
P322 = 6.294
Totalizer Display = 00176.294
Totalizer units are dependent upon programming. Enter zero 0 (if required) to reset the
totalizer to zero. Alternatively, enter any other (applicable) value, to preset the totalizer to
the necessary value.
Primary Index
Single Point Model Dual Point Model
Global Transducer
Values Range: -999 to 9999 (view only)
Related • P604 Maximum Flow
Primary Index
Single Point Model Dual Point Model
Global Transducer
Values Range: -999 to 9999 (view only)
Related • P604 Maximum Flow
Note: A second point is available only if the Dual Point Feature is enabled.

Siemens MAG 5000 Specifications

General

Type	Electromagnetic Flowmeter
Protection Class	IP67
Material	Stainless Steel, Carbon Steel
Power Supply	24 V DC, 100-240 V AC
Accuracy	±0.2% of flow rate
Communication	HART, PROFIBUS, Modbus
Enclosure Rating	IP67
Ambient Temperature Range	-20°C to +60°C
Sizes	DN 2 to DN 3000
Lining Materials	PTFE, Hard Rubber
Electrode Materials	Stainless Steel, Hastelloy, Tantalum
Process Temperature	-40 to +180 °C (-40 to +356 °F) depending on liner
Process Pressure	Up to 40 bar (580 psi)
Approvals	ATEX, FM, CSA, IECEx
Flow Velocity Range	0 to 12 m/s
Output Signals	4-20 mA, Pulse, Frequency
