Page 48 MultiRanger 100/200 – INSTRUCTION MANUAL 7ML19981FB05
mmmmm
mA LI/O
mA I/O
To integrate the MultiRanger with other equipment, use the mA input and outputs.
The mA input can be used as a level measurement or can be passed on to a SCADA
system.
mA Input [MR 200]
Level Reading Parameters
To pass the mA input on to a SCADA system, read the value from the appropriate
communication registers. For more information, go to the
MultiRanger Communications
section on page 89.
mA Output
The MultiRanger has two mA outputs, used to send measurements to other devices.
Configuring the mA output to send a 4 to 20 mA signal scaled from 10% to 90% of span of
the second transducer:
Note: When a mA input parameter is accessed, a mA symbol appears in the
upper left corner of the LCD display.
Parameter Index Value Description
P004 1 250 Transducer = mA input 1
P250 1 2 Scale = 4 to 20 mA
P251 1 0 4 mA = 0% of span
P252 1 100 20 mA = 100% of span
P253 1 0 Do not damp the input signal
Parameter Index Value Description
P200 1 2 set to 4 to 20 range
P201 1 1 send mA proportional to level reading
P202 1 2 base mA on level point 2
P210 1 10
set 4 mA at 10% of span
1
1.
If the level reading drops below 10% of span, the mA output drops below
4 mA.
P211 1 90
set 20 mA at 90% of span
2
2.
If the level reading rises above 90% of span, the mA output rises above
20 mA.
P219 1 0 set failsafe action as 0 mA

Siemens MAG 5000 Specifications

General

Type	Electromagnetic Flowmeter
Protection Class	IP67
Material	Stainless Steel, Carbon Steel
Power Supply	24 V DC, 100-240 V AC
Accuracy	±0.2% of flow rate
Communication	HART, PROFIBUS, Modbus
Enclosure Rating	IP67
Ambient Temperature Range	-20°C to +60°C
Sizes	DN 2 to DN 3000
Lining Materials	PTFE, Hard Rubber
Electrode Materials	Stainless Steel, Hastelloy, Tantalum
Process Temperature	-40 to +180 °C (-40 to +356 °F) depending on liner
Process Pressure	Up to 40 bar (580 psi)
Approvals	ATEX, FM, CSA, IECEx
Flow Velocity Range	0 to 12 m/s
Output Signals	4-20 mA, Pulse, Frequency
