7ML19981FB05 MultiRanger 100/200 – INSTRUCTION MANUAL Page 249
mmmmm
Appendix G
General Appendix G: Conduit Entry for
Class 1, Div 2 Applications
2365031400
S. NGUYEN PETERBOROUGH 14/ AUG / 02 ULTRASONICS
FOR CONSTRUCTION
0
T. AD AM R. CLYSDALE
1 : 1
1
2
NONE
HINGED 6 X 9 ENCLOSURE WITH CONDUIT ENTREES & ASSEMBLE FOR CLASS 1 DIV 2 APPLICATIONS
23650314
0
RPC
SN
AUG
14/02
6.33
1.688
9.46
0.94
0.875
1.50
2.62
3.25
4.625
DRILL FOR 1/2” CONDUIT HUBS
DRILL FOR 3/4” CONDUIT HUB
NOTES:
1) USE ONLY CONDUIT HUBS CERTIFIED / APPROVED AS TYPE 4X. 2) NON METALLIC ENCLOSURE DOES NOT PROVIDE GROUNDING BETWEEN CONDUIT CONNECTIONS. USE GROUNDING TYPE BUSHINGS AND JUMPER WIRES. 3) DIMENSIONS INCHES
WARNING
: – SUBSTITUTION OF COMPONENTS MAY IMPAIR
SUITIBILITY FOR CLASS I, DIVISION 2
EXPLOSION HAZARD
Product Group

Siemens MAG 5000 Specifications

General

Type	Electromagnetic Flowmeter
Protection Class	IP67
Material	Stainless Steel, Carbon Steel
Power Supply	24 V DC, 100-240 V AC
Accuracy	±0.2% of flow rate
Communication	HART, PROFIBUS, Modbus
Enclosure Rating	IP67
Ambient Temperature Range	-20°C to +60°C
Sizes	DN 2 to DN 3000
Lining Materials	PTFE, Hard Rubber
Electrode Materials	Stainless Steel, Hastelloy, Tantalum
Process Temperature	-40 to +180 °C (-40 to +356 °F) depending on liner
Process Pressure	Up to 40 bar (580 psi)
Approvals	ATEX, FM, CSA, IECEx
Flow Velocity Range	0 to 12 m/s
Output Signals	4-20 mA, Pulse, Frequency
