Communications
MultiRanger Communications
MultiRanger Communication Systems
The MultiRanger is an integrated level controller capable of communicating process
information to a Supervisory Control and Data Acquisition (SCADA) system, via a serial
device such as a radio modem, leased line, or dial-up modem.
The standard MultiRanger supports the following two communication protocols:
Modbus
Modbus is an industry standard protocol used by SCADA and HMI systems. The
MultiRanger uses Modbus to communicate via the RS-485 port. For a description of the
Modbus protocol, contact your local Schneider representative.
Dolphin
Dolphin is a proprietary Siemens Milltronics protocol designed to be used with Dolphin
Plus. For more information on Dolphin Plus or to obtain a copy of the software, please go
to www.siemens.com/processautomation
to contact your Siemens Milltronics
representative.
Optional SmartLinx
®
Cards
The standard MultiRanger unit may also be enhanced with Siemens Milltronics
SmartLinx
®
communication modules that provide an interface to popular industrial
communication systems.
This manual only describes the built-in communications. For more information on
SmartLinx, please consult the appropriate SmartLinx manual.
MultiRanger
Connection via radio modem, dial-up modem, or leased line modem

Siemens MAG 5000 Specifications

General

Type	Electromagnetic Flowmeter
Protection Class	IP67
Material	Stainless Steel, Carbon Steel
Power Supply	24 V DC, 100-240 V AC
Accuracy	±0.2% of flow rate
Communication	HART, PROFIBUS, Modbus
Enclosure Rating	IP67
Ambient Temperature Range	-20°C to +60°C
Sizes	DN 2 to DN 3000
Lining Materials	PTFE, Hard Rubber
Electrode Materials	Stainless Steel, Hastelloy, Tantalum
Process Temperature	-40 to +180 °C (-40 to +356 °F) depending on liner
Process Pressure	Up to 40 bar (580 psi)
Approvals	ATEX, FM, CSA, IECEx
Flow Velocity Range	0 to 12 m/s
Output Signals	4-20 mA, Pulse, Frequency
