7ML19981FB05 MultiRanger 100/200 – INSTRUCTION MANUAL Page 25
mmmmm
Operation
Setting the Default Auxiliary Reading
To maintain a constant variable display in the auxiliary reading area, set the default.
Example:
To leave the level reading on the screen and view the echo confidence in the auxiliary
reading field, set the following parameter:
Setting a Specific Auxiliary Reading
To display a second auxiliary reading, press in RUN mode.
Example: To set to display current temperature, go to P731:
Multiple Readings [MR 200 only]
During differential or average operation (P001 = 4 /5), the display scrolls sequentially
through Point Numbers 1, 2, and 3. Point 3 is the difference between (or average of) Points
1 and 2.
Changing Number Scrolling Speed
See Parameter Indexing on page 36. All the instructions in the following procedures apply
to the hand programmer and assume that the MultiRanger is activated.
Parameter Index Value Description
P730 G 805 Auxiliary field defaults to P805
Parameter Index Value Description
P731 G 912 Shows P912–Transducer Temperature
Parameter Index Value Description
P732 G 5 Hold each value for 5 seconds
P
P

Siemens MAG 5000 Specifications

General

Type	Electromagnetic Flowmeter
Protection Class	IP67
Material	Stainless Steel, Carbon Steel
Power Supply	24 V DC, 100-240 V AC
Accuracy	±0.2% of flow rate
Communication	HART, PROFIBUS, Modbus
Enclosure Rating	IP67
Ambient Temperature Range	-20°C to +60°C
Sizes	DN 2 to DN 3000
Lining Materials	PTFE, Hard Rubber
Electrode Materials	Stainless Steel, Hastelloy, Tantalum
Process Temperature	-40 to +180 °C (-40 to +356 °F) depending on liner
Process Pressure	Up to 40 bar (580 psi)
Approvals	ATEX, FM, CSA, IECEx
Flow Velocity Range	0 to 12 m/s
Output Signals	4-20 mA, Pulse, Frequency
