7ML19981FB05 MultiRanger 100/200 – INSTRUCTION MANUAL Page 55
mmmmm
Alarms
In Bounds/ Out of Bounds Range [MR 200]
Use the bounded range alarms to detect when the level is inside or outside of the range.
By using a bounded range alarm, you can effectively put two level alarms (high and low)
on one relay.
Setting an Out of Bounds Alarm
Results:
• Trips alarm above 1.35 m and below 0.25m
• Resets alarm below 1.25 m and above 0.35m
Setting an In Bounds Alarm
Results:
• Trips alarm below 1.25 m and above 0.35 m
• Resets alarm above 1.35 m and below 0.25 m
Cable Fault
Activates an alarm if transducer cable circuit enters a shorted or opened state.
Temperature [MR 200]
Use the temperature alarm to activate an alarm when the temperature reaches the ON
setpoint (P112). This alarm uses the same setpoint parameters as the level alarms (P112
and P113).
Parameter Index Value
P111 5 3
P112 5 1.3
P113 5 0.3
P116 5 0.05
Parameter Index Value
P111 5 2
P112 5 1.3
P113 5 0.3
P116 5 0.05
Parameter Index Value Description
P111 5 7 Alarm on transducer cable fault
P110 5 1 Alarm on Transducer One

Siemens MAG 5000 Specifications

General

Type	Electromagnetic Flowmeter
Protection Class	IP67
Material	Stainless Steel, Carbon Steel
Power Supply	24 V DC, 100-240 V AC
Accuracy	±0.2% of flow rate
Communication	HART, PROFIBUS, Modbus
Enclosure Rating	IP67
Ambient Temperature Range	-20°C to +60°C
Sizes	DN 2 to DN 3000
Lining Materials	PTFE, Hard Rubber
Electrode Materials	Stainless Steel, Hastelloy, Tantalum
Process Temperature	-40 to +180 °C (-40 to +356 °F) depending on liner
Process Pressure	Up to 40 bar (580 psi)
Approvals	ATEX, FM, CSA, IECEx
Flow Velocity Range	0 to 12 m/s
Output Signals	4-20 mA, Pulse, Frequency
