Siemens MAG 5000 User Manual

75
SITRANS F M
8. Commissioning
8.6.1
Settings available
Parameter Factory settings Settings available
Password
Default value 1000
Password 1000 1000 ... 9999
Basic settings
Flow direction Positive Positive, negative
Q
max.
Dim. dependent Dim. dependent
- Volume units Dim. dependent m
3
, ml, l, kl, hl, Ml, ft
3
, in
3
, USG, USkG, USMG, UKG,
UKMG, USBBL
- Time units Dim. dependent Sec., min., hour, day
Totalizer 1 Forward Forward, reverse, net
- Totalizer 1 units Dim. dependent m
3
, ml, l, kl, hl, Ml, ft
3
, in
3
, USG, USkG, USMG, UKG,
UKMG, USBBL
Totalizer 2 Reverse Forward, reverse, net
- Totalizer 2 units Dim. dependent m
3
, ml, l, kl, hl, Ml, ft
3
, in
3
, USG, USkG, USMG, UKG,
UKMG, USBBL
Low flow cut-off 1.5 % 0 ... 9.9 %
Empty pipe Off Off, on
Error level Warning Fatal, permanent, warning
Output
Current output Off On/off, uni-/bidirectional, 0/4 - 20 mA
- Time constant 5 s 0.1 ... 30 s
Digital output Pulse Error, direction/limit, batch
1)
, frequency, pulse, error no.,
off
Relay output Error Error, direction/limit, cleaning, error no., off
Direction/limit switch Off 1 set point/2 set points, −100 ... +100%
- Hysteresis 5% 0.0 ... 100%
Batch
1)
Off
- Batch quantity 0 Dim. dependent
- Batch compensation 0 −100 ... +100 m
3
- Batch counter Down Up/down
- Time constant 0.1 s 0.1 ... 30 s
Frequency Off 500 Hz, 1 kHz, 5 kHz, 10 kHz
- Time constant 5 s 0.1 ... 30 s
Pulse On
- Pulse polarity Positive Positive/negative
- Pulse width 66 ms 64 μs, 130 μs, 260 μs, 510 μs, 1.0 ms, 2.0 ms,
4.1 ms, 8.2 ms, 16 ms, 33 ms, 66 ms, 130 ms,
260 ms, 520 ms, 1.0 s, 2.1 s, 4.2 s.
- Volume/pulse Dim. dependent Dim. dependent
- Time constant 0.1 s 0.1 ... 30 s
Electrode cleaning Off Off/cleaning
- Cleaning cycle time 24 h 1 ... 240 h
External input
External input Off Batch, reset totalizer, freeze output, forced output, off
- Batch Start, hold/continue, stop, Q
max.
2
Sensor characteristics
Correction factor 1 0.85 ... 2.00
Language English English, German, French, Danish, Swedish, Finnish,
Spanish, Russian, Italian, Portuguese and Polish
Operator menu
Primary field Flow rate Flow rate, Totalizer 1, Totalizer 2
Title/subtitle line Flow rate Flow rate, Flow rate %, Q
max.
, Totalizer 1, Totalizer 2,
Totalizer 1 reset, Totalizer 2 reset, Batch start/paused/
stop, Batch cycle counter, Batch cycle counter reset,
Sensor size, Sensor type, Error pending, Status log, Tag No.
1)
Batch is available on MAG 6000 only
The transmitter is delivered with factory settings ready to measure the actual flow.

Siemens MAG 5000 Specifications

General

Type	Electromagnetic Flowmeter
Protection Class	IP67
Material	Stainless Steel, Carbon Steel
Power Supply	24 V DC, 100-240 V AC
Accuracy	±0.2% of flow rate
Communication	HART, PROFIBUS, Modbus
Enclosure Rating	IP67
Ambient Temperature Range	-20°C to +60°C
Sizes	DN 2 to DN 3000
Lining Materials	PTFE, Hard Rubber
Electrode Materials	Stainless Steel, Hastelloy, Tantalum
Process Temperature	-40 to +180 °C (-40 to +356 °F) depending on liner
Process Pressure	Up to 40 bar (580 psi)
Approvals	ATEX, FM, CSA, IECEx
Flow Velocity Range	0 to 12 m/s
Output Signals	4-20 mA, Pulse, Frequency
