Page 150 MultiRanger 100/200 – INSTRUCTION MANUAL 7ML19981FB05
mmmmm
Parameters
P213 mA Output Max Limit
Sets the maximum mA output value (in mA) to be produced.
mA Output Trim (P214 to P215)
This does not affect the P203 value shown, and is used when recalibration of an external
device is impractical.
To adjust the value so that the device correctly indicates 4.00 (when P214 is accessed) or
20.00 mA (when P215 is accessed):
1. Attach ammeter to HydroRanger 200 mA output.
2. Access P214, Index 1 (for mA output 1) or 2 (for mA output 2). Press CLEAR and
ENTER . The ammeter should show a value near 4 mA.
3. Enter the exact value displayed on the ammeter into P214 (Index 1 or 2).
4. The ammeter should then read exactly 4.00 mA.
5. Repeat steps 1 to 4 to set P215, using 20 mA as the desired value.
P214 4 mA Output Trim
Calibrates the 4 mA output.
Adjust this value so the device indicates 4.000 mA when P214 is accessed.
P215 20 mA Output Trim
Calibrates the 20 mA output.
Adjust this value so the device indicates 20.00 mA when P215 is accessed.
Primary Index mA output
Values
Range: 0.000 to 22.00
Preset: 20.2 mA
Related P200 mA Output Range / P212 mA Output Min LImit
Primary Index mA output
Values Range: 0 to 9999
Related P215 20 mA Output Trim
Primary Index mA output
Values Range: 0 to 16000
Related P214 4mA Output Trim
