Page 248 MultiRanger 100/200 – INSTRUCTION MANUAL 7ML19981FB05
mmmmm
Appendix F: Upgrading
MultiRanger Plus to MultiRanger 100/200 Parameters
The MultiRanger 100/200 uses the current Siemens Milltronics standard parameter set
which is different than the parameter numbers used in the MultiRanger Plus.
The MultiRanger Plus parameters numbers are sequential (P-0 to P-99). The MultiRanger
100/200 parameters number are also sequential; however, some of the parameters are
indexed.
Parameters are indexed when they apply to more than one input or output. The index
value defines the input/output for that parameter. Indexed parameters contain a value for
each index, even if that index is not used.
Example
In the MultiRanger Plus each relay had a dedicated parameter number for its function,
ON and OFF points.
MultiRanger Plus Relay One
• P-8: Function
• P-9 : ON setpoint
• P-10: OFF setpoint
MultiRanger 100/200 uses P111 for all relays and indexes these parameters.
• P-111: Function
•P-112: ON
• P-113: OFF
The following tables show the differences between the MultiRanger Plus and the
MultiRanger 100/200. They each show one relay programmed as a high alarm, and two
relays programmed for pump control with alternating pump starts:
MultiRanger Plus
Relay Parameter Value
1 P- 8 ( r ela y f u nc ti on ) 1 (alarm)
1 P-9 (ON setpoint) 4 m
1 P10 (OFF setpoint) 3.5 m
2 P- 11 ( rel ay f un ct io n ) 9
2 P-12 (ON setpoint) 3.2 m
2 P-13 (OFF setpoint) 0.5 m
3 P- 14 ( r ela y f u nc ti on ) 9
3 P-15 (ON setpoint) 3.4 m
3 P-16 (OFF setpoint) 0.6 m
MultiRanger 100/200
Relay Parameter Value
1 P111 [1] (relay function) 1
1 P112 [1] (ON setpoint) 4 m
1 P113[1] (OFF setpoint) 3.5 m
2 P111[2] (relay function) 52
2 P112[2] (ON setpoint) 3.2 m
2 P113[2] (OFF setpoint) 0.5 m
3 P111[3] (relay function) 52
3 P112[3] (ON setpoint) 3.4 m
3 P113[3] (OFF setpoint) 0.6 m
