7ML19981FB05 MultiRanger 100/200 – INSTRUCTION MANUAL Page 69
mmmmm
Rake (Screen) Control
MR 200
Setting the Common Parameters
Prerequisite: Substitute the details of your application in place of the sample values
provided. If you are bench testing the unit, set your test values to be the same as the
sample values.
Set Relay 1 (Operate Rake)
Set Relays 2 to 4 (Level Alarms)
Parameter Index Value Description
P001 G 4 Operation = Differential
P002 G 1 Material = liquid
P003 1,2 2 Max. Process Speed = medium
P004 1,2 102 Transducer = XPS-10
P005 G 1 Units = meters
P006 1
2
1.8
2.2
Empty
Empty
= 1.8m
= 2.2m
P007 1
2
3
1.4
1.4
1.4
Span
Span
Max Differential
= 1.4m
= 1.4m
= 1.4m
Parameter Index Value Description
P110 1 3
Starts the rake when the difference between the
two levels rises above 0.4m and stop the rake
when the difference falls below 0.1m.
P111 1 50
P112 1 0.4
P113 1 0.1
P110 2 1 Description
P110 2 1
Sets Relay Two as a high level alarm for
Transducer One with an ON setpoint of 1.3m
and an OFF setpoint of 1.2m.
P111 2 1
P112 2 1.3
P113 2 1.2
P110 3 2
Sets Relay Three as a low level alarm for
Transducer Two with an ON setpoint of 0.2m
and an OFF setpoint of 0.4m.
P111 3 1
P112 3 0.2
P113 3 0.4
P110 4 3 Sets Relay Four as a rake failure alarm as it
uses the differential level point (3) with an
ON setpoint of 1.0m and an OFF setpoint of
0.9m.
P111 4 1
P112 4 1.0
P113 4 0.9

Siemens MAG 5000 Specifications

General

Type	Electromagnetic Flowmeter
Protection Class	IP67
Material	Stainless Steel, Carbon Steel
Power Supply	24 V DC, 100-240 V AC
Accuracy	±0.2% of flow rate
Communication	HART, PROFIBUS, Modbus
Enclosure Rating	IP67
Ambient Temperature Range	-20°C to +60°C
Sizes	DN 2 to DN 3000
Lining Materials	PTFE, Hard Rubber
Electrode Materials	Stainless Steel, Hastelloy, Tantalum
Process Temperature	-40 to +180 °C (-40 to +356 °F) depending on liner
Process Pressure	Up to 40 bar (580 psi)
Approvals	ATEX, FM, CSA, IECEx
Flow Velocity Range	0 to 12 m/s
Output Signals	4-20 mA, Pulse, Frequency
