7ML19981FB05 MultiRanger 100/200 – INSTRUCTION MANUAL Page 117
mmmmm
Parameters
Parameter Reference
The MultiRanger is configured through its parameters, and the application determines
the parameter values which are entered into the unit.
Please check your value entries carefully before operating the MultiRanger to ensure
optimum performance.
MultiRanger 100 and MultiRanger 200
All MultiRanger 100 and MultiRanger 200 parameters are listed in this section.
MultiRanger 200 parameters are identified separately. The parameter title includes this
marking [MR 200], indicating that parameter applies to the MultiRanger 200 only.
As a general rule, parameters affecting volume apply only to the MultiRanger 200.
Helpful Hints
Please note the following:
• Default values are always indicated with an asterix (*)
• Global values are common for all inputs and outputs on the unit
• Indexed parameters can apply to more than one input or output
• Primary index relates to an input or output
• Secondary index allows for multiple values on an indexed point
Accessing a Secondary Index
1. Press MODE , and then press DISPLAY to activate secondary index.
The icon appears under the index field.
2. Enter the secondary index, and then enter the values to set the secondary index.

Siemens MAG 5000 Specifications

General

Type	Electromagnetic Flowmeter
Protection Class	IP67
Material	Stainless Steel, Carbon Steel
Power Supply	24 V DC, 100-240 V AC
Accuracy	±0.2% of flow rate
Communication	HART, PROFIBUS, Modbus
Enclosure Rating	IP67
Ambient Temperature Range	-20°C to +60°C
Sizes	DN 2 to DN 3000
Lining Materials	PTFE, Hard Rubber
Electrode Materials	Stainless Steel, Hastelloy, Tantalum
Process Temperature	-40 to +180 °C (-40 to +356 °F) depending on liner
Process Pressure	Up to 40 bar (580 psi)
Approvals	ATEX, FM, CSA, IECEx
Flow Velocity Range	0 to 12 m/s
Output Signals	4-20 mA, Pulse, Frequency
