7ML19981FB05 MultiRanger 100/200 – INSTRUCTION MANUAL Page 167
mmmmm
Parameters
Example Exponents
P602 Primary Measuring Device Dimensions [MR 200]
The dimensions of the Primary Measuring Device (PMD).
Use this parameter if the Primary Measuring Device is directly supported (P600=2,3,6,7).
The dimensions required for each PMD vary.
For more information on PMD, see page 72.
PMD Type Exponent (sample only)
Suppressed Rectangular Weir 1.50
Cipolletti Weir 1.50
Venturi Flume 1.50
Parshall Flume 1.22 to 1.607
Leopold Lagco 1.547
V-Notch Weir 2.50
Primary Index
Single Point Model Dual Point Model
Global Transducer and Dimension
Secondary Index Dimension
Index Values for
Supported PMDs
ISO 1438/1
1Notch Angle
2 Discharge Coefficient
ISO 4359
1Approach width
2Throat width
3Hump Height
4 Throat Length
5 Velocity coefficient
6 Discharge coefficient
Palmer Bowlus
1Flume width
H Flume
1 Flume height
Altered By • P600 Primary Measuring Device

Siemens MAG 5000 Specifications

General

Type	Electromagnetic Flowmeter
Protection Class	IP67
Material	Stainless Steel, Carbon Steel
Power Supply	24 V DC, 100-240 V AC
Accuracy	±0.2% of flow rate
Communication	HART, PROFIBUS, Modbus
Enclosure Rating	IP67
Ambient Temperature Range	-20°C to +60°C
Sizes	DN 2 to DN 3000
Lining Materials	PTFE, Hard Rubber
Electrode Materials	Stainless Steel, Hastelloy, Tantalum
Process Temperature	-40 to +180 °C (-40 to +356 °F) depending on liner
Process Pressure	Up to 40 bar (580 psi)
Approvals	ATEX, FM, CSA, IECEx
Flow Velocity Range	0 to 12 m/s
Output Signals	4-20 mA, Pulse, Frequency
