2. Technical data
SITRANS F M
Type MAG 1100 MAG 1100 HT (High temperature)
Enclosure rating IP67 to EN 60529 (NEMA 4X), 1 mH
2
O for 30 min
EMC 89/336 EEC
Design
Weight See dimensional drawings See dimensional drawings
Material
• Enclosure
- MAG 1100 Stainless steel AISI 316L (1.4404) Stainless steel AISI 316L (1.4404)
• Terminal box
- Standard Fibre glass reinforced polyamide (no ATEX) Stainless steel AISI 316 (1.4436)
- Option Stainless steel AISI 316 (1.4436) (ATEX)
• Fixing studs Stainless steel AISI 304 (1.4301), Stainless steel AISI 304 (1.4301),
Number and size to EN 1092-1:2001 Number and size to EN 1092-1:2001
• Gaskets
- Standard EPDM (max. 150 °C, PN 40 (max. 300 °F, 600 psi)) Graphite (max. 200 °C, PN 40 (max. 390 °F, 600 psi))
- Option • Graphite (max. 200 °C, PN 40 (max. 390 °F, 600 psi))
• PTFE (max. 130 °C, PN 25 (max. 270 °F, 300 psi))
• Pipe connection adapters:
DN 2, 3, 6 and 10 (
1
/
12
",
1
/
8", ¼" and
3
/
8") • Stainless steel, AISI 316
• Hastelloy C22
• PVDF
Liner
• MAG 1100 (Ceramic) • DN 2, 3 (
1
/
12
"
,
1
/
8
"
): Zirconium oxide (ZrO
2
) DN 15 ... 100 (½
"
... 4
"
): Aluminium oxide Al
2
O
3
• DN 6 ... 100 (¼
"
... 4
"
): Aluminium oxide Al
2
O
3
• Reinforced PFA (no ATEX)
Electrodes
• MAG 1100 (Ceramic) • DN10 ... 100 (
3
/
8
" ... 4") : Platinum with gold / Platinum with gold / Titanium brazing alloy
Titanium brazing alloy
• DN 2 ... 6 (
1
/
12
"
... ¼
"
): Platinium
• MAG 1100 (PFA) • DN 10 ... 15 (
3
/
8
" ... ½"): Hastelloy C276
• DN 25 ... 100 (1" ... 4"): Hastelloy C22
Cable entries • Remote installation 2 x M20 or 2 x½ NPT Remote installation 2 x M20 or 2 x ½
"
NPT
• Compact installation
- MAG 5000/MAG 6000: 4 x M20 or 4 x ½" NPT
Certificates and approvals
Conforms to PED – 97/23 EC and CRN (PFA) PED – 97/23 EC and CRN (PFA)
Custody Transfer
(MAG 5000/6000 CT) Cold water pattern approval PTB (Germany) Heat meter pattern approval - OIML R 75 (Denmark)
Heat meter pattern approval - OIML R 75 (Denmark) Hot water pattern approval - PTB (Germany)
Hot water pattern approval - PTB (Germany)
Other media than water pattern approval -
OIML R 117 (Denmark)
Ex approvals
MAG 1100 (Ceramic)
• ATEX sensor ATEX 2G D sensor Ex d e ia IIB T3 - T6 ATEX 2G D sensor Ex d e ia IIB T3 - T6
• Sensor with/without FM Class 1 div 2 FM Class 1 div 2
MAG 5000/6000
MAG 1100 (PFA)
• Sensor with/without
MAG 5000/6000 FM Class 1 div 2
1)
Conditions are also dependent on liner characteristics
For technical specifications for transmitter - please see transmitter pages.

Siemens MAG 5000 Specifications

General

Type	Electromagnetic Flowmeter
Protection Class	IP67
Material	Stainless Steel, Carbon Steel
Power Supply	24 V DC, 100-240 V AC
Accuracy	±0.2% of flow rate
Communication	HART, PROFIBUS, Modbus
Enclosure Rating	IP67
Ambient Temperature Range	-20°C to +60°C
Sizes	DN 2 to DN 3000
Lining Materials	PTFE, Hard Rubber
Electrode Materials	Stainless Steel, Hastelloy, Tantalum
Process Temperature	-40 to +180 °C (-40 to +356 °F) depending on liner
Process Pressure	Up to 40 bar (580 psi)
Approvals	ATEX, FM, CSA, IECEx
Flow Velocity Range	0 to 12 m/s
Output Signals	4-20 mA, Pulse, Frequency
