Procedure
1. For every block listed, open the "General" tab and the "I\Os" tab in the "Object Properties"
dialog box.
2. Enter the parameters for all blocks according to the table below.
Block Block name in
the project
I/O Meaning Value
Pcs7AnIn INPUT_U Mode Value status and measur‐
ing type
16#00000203
PV_In Process value (raw value) 16#0203
PV_InUnit Unit of measure for process
value
1348
SimOn.Value 1 = Simulation on 1
SubsPV_In Substitute value 15.0
DoseL DOSE CR_A_DC Creep flow: Delay time for
incoming alarms [s]
5.0
CR_AH_Lim Creep flow: Limit high alarm 5.0
CR_Hyst Creep flow: Hysteresis for
alarm limit
0.2
DQ_AH_Tol Overdosage: Limit high
alarm
3.0
DQ_ExHiAct.Value Default for the internal\ex‐
ternal switchover
1
DQ_Ext.Value Dosing quantity: External
setpoint
111.0
DQ_HiLim.Value Limit dosing quantity 500.0
DQ_Int End value dosing quantity 20.0
DQ_OpScale.High Dosing quantity: High scale
limit of bar graph
550.0
DQ_Unit Unit of dosing in m³ 1034
DQ2_ExHiAct.Value Dosing quantity: 1 = High
limit for external setpoint
factor for fine dosing has
been reached
1
DQ2_Ext.Value External fine dosing quanti‐
ty
15.0
DQ2_HiLim.Value Fine dosing: Limit high set‐
point
350.0
DQ2_Int Fine dosing quantity 11.0
Feature.Bit16 1
Feature.Bit4 Set switch or button mode 1
Feature.Bit6 Reset dosing quantity when
dosing starts
1
PV_AH_Lim High display limit of the
process value for the dos‐
ing volume
700.0
PV_OpScale.High Process value: High scale
limit of bar graph
350.0
Creating CFCs
6.6 Working with the CFC Editor
PCS 7 SMART Getting Started - Part 1 (V9.0 with APL)
86 Getting Started, 12/2017, A5E42181435-AA
