Block Block name in
the project
I/O Meaning Value
SP.Value Active flow setpoint 70.0
SP_Ext.Value External manipulated value 120.0
SP_ExtAct.Value Active external setpoint 1
SP_HiLim.Value Coarse dosing: High limit
setpoint flow
70.0
SP_Int Coarse dosing setpoint 70.0
SP_LiOp.Value 1=Linking, 0=Operator Ac‐
tive
1
SP_TrkExt 1 = Bumpless switchover
from external to internal set‐
point active
0
SP2_Ext.Value Fine dosing external set‐
point
15.0
SP2_HiLim.Value Fine dosing: High limit set‐
point flow
15.0
SP2_Int Fine dosing setpoint 9.0
TI.Value Reset time 30.0
Mul04 MUL In2.Value Value to be multiplied 1
In3.Value The value to be multiplied
(value as percentage)
0.01
PIDConL CTRL_PID AutModLi.Value Interconnection to automat‐
ic
1
ModLiOp.Value Interconnection automatic/
manual active
1
MV_HiLim.Value High limit for manipulated
value
99.0
PV_AH_Lim Process value alarm: High
limit
70.0
PV_AH_En 1 = Enable PV alarm limit
(high)
1
PV_AL_En 1 = Enable PV alarm limit
(low)
0
PV_WH_En 1 = Enable PV warning limit
(high)
0
PV_WL_En 1 = Enable PV warning limit
(low)
0
PV_TH_En 1 = Enable PV alarm limit
(high)
0
PV_TL_En 1 = Enable PV alarm limit
(low)
0
PV_OpScale.High Process value: High scale
limit of bar graph
70.0
SP_Ext.Value External manipulated value 70.0
SP_ExtLi.Value Interconnection for the in‐
ternal/external switchover
active
1
Creating CFCs
6.6 Working with the CFC Editor
PCS 7 SMART Getting Started - Part 1 (V9.0 with APL)
Getting Started, 12/2017, A5E42181435-AA 87
