Siemens simovert masterdrives

-755 -
Function diagram
87654321
fp_mc_755_e.vsd
Free blocks
MASTERDRIVES MC
23.10.02
Characteristic blocks, dead zone
V2.5
x
z
-z
y
x
y
x
y1
x
y
+200%
x10
x1
1
2
3
4
6
5
7
8
9
10
y10
-200%
y
x
y1
x
y
+200%
x10
x1
1
2
3
4
6
5
7
8
9
10
y10
-200%
y
3 characteristic blocks with 10 support values (1-word) {8 µs}
1 dead zone (1-word) {1 µs}
x
y1
x
y
+200%
x10
x1
1
2
3
4
6
5
7
8
9
10
y10
-200%
y
K0541
U951.07 = __ (20)
K
U190 (0)
X values
U191.01 to .10 (0)
Y values
U192.01 to .10 (0)
K0542
U951.33 = __ (20)
K
U193 (0)
X values
U194.01 to .10 (0)
Y values
U195.01 to .10 (0)
K0543
U952.09 = __ (20)
K
U196 (0)
X values
U197.01 to .10 (0)
Y values
U198.01 to .10 (0)
K0544
U950.88 = __ (20)
K
U199 (0)
Dead zone z
U200 (0,00)
The distance
between 2 adjacent
X or Y values must
not be more than
199.99 %.
The distance
between 2 adjacent
X or Y values must
not be more than
199.99 %.
The distance
between 2 adjacent
X or Y values must
not be more than
199.99 %.
