Siemens simovert masterdrives

Function diagram
87654321
fp_mc_841_e.vsd
Technology option
MASTERDRIVES MC
02.02.04
Synchronism - Synchronization, displacement angle setting
-841 -
V2.5
+
(for sheet [834] ...[843])
Limitation to ACL
SET
SET
VALUE
RESET
Current displacement [841.8]
<2>
Displacement angle absolute
s.set_Slave
[836.6]
Current displacement [841.8]
Displacement angle relative
s_set_Slave
[836.6]
.01
.02
Start +
Start -
Inching displacement angle
t
t
v
s_inch
.01
.02
Inch +
Inch -
v_inch
s
s_Master_Slave
+
+
+
+
+
s_relative
+
+
t
t
v
s
s
V_displacement
[836.1]
Compensation movement
MD11
POWER ON
<2> A "current displacement" which may
be generated by other displacement
settings is taken into account
[836.6]
during change of values
Memory
+
-
SET
[%]
x1
x2
x1 x2
100%
*
x1
x2
x1 x2
100%
*
<3>
[841.2]
<3> Limited to axis cycle
[DI_RP]
[DI_RN]
[DI_JP]
[DI_JN]
.01
.02
Synchronizing to master
setpoint
See function diagram [841a]
KK
U678.01(813)
Absolute displacement angle
KK0813
KK
U678.3 (814)
Relative displacement angle
KK0814
B
U694 (0)
KK
U698.02 (1)
Factor [%]
B
U696 (0)
B0811
Synchronizing status
1= "is synchronized"
KK
U698.01 (1)
Factor
KK0827
Residual
displacement
B0810
Adjustm. active
KK0812
Current displacement
(for visualizing or
for non-volatile
storage by means
of tracking/
storage element
[760] )
KK
U678.02 (0)
Displacement set value
(e.g. from tracking/storage element
[760])
B
U672 (0)
Set displacement
U953.33=___ (20)
n465
KK0829
V [% (U697.2)]
B (1)
U464
Enable adj.
Adjust
displacem.
B (811)
B
U676 (0)
Synchronizing to master setpoint
Operating mode of correction
U699.1 (0)
-2
31
...2
31
[LU]
U677.01 (0)
-2
31
...2
31
[LU]
U677.02 (0)
Adjustment speed
0.00 … 20 000 000.00 [1000 LU/min]
U695.1 (60000.00)
B
Acceleration
0.00 … 20 000 000.00 [1000 LU/s
2
]
U695.2 (0)
Deceleration
0.00 … 20 000 000.00 [1000 LU/s
2
]
U695.3 (0)
Operating mode of correction
0 = shortest distance
1 = as specified (new value >
old value => pos. direction)
U699.2 (1)
B
Mode relative to displacement angle setting
0 = Additive
1 = Delete residual displacement
U670 (0)
n466.2
n466.1
Adjusting speed
0.00 … 20 000 000.00 [1000 LU/min]
U697.2 (60000.00)
Acceleration
0.00 … 20 000 000.00 [1000 LU/s
2
]
U697.1 (0)
