Siemens simovert masterdrives Compendium

Parameter
Description Data Read/write
P032*
S.Disp Conn
32
BICO parameter for selecting connectors which are to be
displayed in visualization parameter r033 in [%]. The
connector numbers shown in the respective index are
displayed in the same index of parameter r033.
In function diagram:
30.1
index1: 0
Unit: -
Indices: 5
Type: L2 ,K
,K
Menus:
- Parameter menu
+ General parameters
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
r033
Display Conn
33
Visualization parameter for displaying the connectors
given in P032. The connnectors displayed in the
respective index have been selected in the same index of
parameter P032. A connector value of 4000 H or 4000
0000 H is shown at 100 %.
In function diagram:
30.2
Dec.Plc.: 3
Unit: %
Indices: 5
Type: I4
Menus:
- Parameter menu
+ General parameters
- Upread/free access
P034*
S.DispVoltsConn
34
BICO parameter for selecting connectors which contain a
voltage and are to be displayed in visualization parameter
r035 in [V]. The connector numbers entered in the
respective index are displayed in the same index of
parameter r035.
In function diagram:
30.4
index1: 0
Unit: -
Indices: 5
Type: L2 ,K
Menus:
- Parameter menu
+ General parameters
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
r035
Disp Volts Conn
35
Visualization parameter for displaying connectors given in
P034 in [V]. The connectors displayed in the respective
index have been selected in the same index of parameter
P034. The normalization is specified in P351. The
following method of calculation must be used:
r035 = P351 xConnector Value in [%]/100%.
In function diagram:
30.5
Dec.Plc.: 1
Unit: V
Indices: 5
Type: I4
Menus:
- Parameter menu
+ General parameters
- Upread/free access
P036*
S.DispAmpsConn
36
BICO parameter for selecting connectors which contain a
current and are to be displayed in visualization parameter
r037 in [A]. The connector numbers entered in the
respective index are displayed in the same index of
parameter r037.
In function diagram:
30.4
index1: 0
Unit: -
Indices: 5
Type: L2 ,K
Menus:
- Parameter menu
+ General parameters
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
r037
Disp Amps Conn
37
Visualization parameter for the display of connectors
given in P036 in [A]. The connectors displayed in the
respective index have been selected in the same index of
parameter P036. The normalization is specified in P350.
The following method of calculation must be used:
r037 = P350 xConnector Value in [%]/100%.
In function diagram:
30.5
Dec.Plc.: 2
Unit: A
Indices: 5
Type: I4
Menus:
- Parameter menu
+ General parameters
- Upread/free access
P038*
S.DispTorqConn
38
BICO parameter for selecting connectors which contain a
torque and are to be displayed in visualization parameter
r039 in [Nm]. The connector numbers entered in the
respective index are displayed in the same index of
parameter r039.
index1: 0
Unit: -
Indices: 5
Type: L2 ,K
Menus:
- Parameter menu
+ General parameters
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
r039
Disp Torq Conn
39
Visualization parameter for the display of connectors
given in P038 in [Nm]. The connectors displayed in the
respective index have been selected in the same index of
parameter P038. The normalization is specified in P354.
The following method of calculation must be used:
r039 = P354 x Connector Value in [%]/100%.
Dec.Plc.: 2
Unit: Nm
Indices: 5
Type: I4
Menus:
- Parameter menu
+ General parameters
- Upread/free access
4
Siemens AG 6SE7087-6QX70 (Edition AL)
SIMOVERT MASTERDRIVES Compendium Motion Control
