Parameter
Description Data Read/write
r047
Disp Hex Conn
47
Visualization parameter for the display of connectors
given in P046 as a hexadecimal number.
If word connectors have been selected in P046, then
Indices 1 to 5 = Value of the connector
Indices 6 to 10 = 0
If double word connectors have been selected in P046,
then:
Indices 1 to 5 = Upper 16 bits of the connector
Indices 6 to 10 = Corresponding lower 16 bits of the
connector
Example:
KK0091 = 1234 5678
P046.1= 91
r047.1 = 1234
r047.6 = 5678
In function diagram:
30.2
Dec.Plc.: 0
Unit: -
Indices: 10
Type: L2
Menus:
- Parameter menu
+ General parameters
- Upread/free access
P048*
PMU OperDisp
48
Function parameter for selecting parameter whose value
is to be indicated in the operating display of the PMU.
Init: 2
Min: 0
Max: 3999
Unit: -
Indices: -
Type: O2
Menus:
- Parameter menu
+ General parameters
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
P049*
OP OperDisp
49
Function parameter for selecting parameters whose
values are to be shown in the operating display of the
optional OP1S user-friendly operator control panel.
Index 1: 1st line left
Index 2: 1st line right
Index 3: 2nd line (actual value), only visualization
parameters
Index 4: 3rd line (setpoint)
Index 5: 4th line
In function diagram:
For Compact/Chassis units: 60.1
For Compact PLUS units: 61.1
index1: 4
Min: 0
Max: 3999
Unit: -
Indices: 5
Type: O2
Menus:
- Parameter menu
+ General parameters
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
P050*
Language
50
Function parameter for setting the language in which texts
are to be displayed on the optional OP1S user-friendly
operator control panel.
0 = German
1 = English
2 = Spanish
3 = French
4 = Italian
This parameter is not reset during factory setting !
Init: 0
Min: 0
Max: 4
Unit: -
Indices: -
Type: O2
Menus:
- Parameter menu
+ General parameters
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
6
Siemens AG 6SE7087-6QX70 (Edition AL)
SIMOVERT MASTERDRIVES Compendium Motion Control
