03.2010 Parameterization
Siemens AG 6SE7087-6QX70 (Version AL)
SIMOVERT MASTERDRIVES Compendium Motion Control 5-3
The parameter menus have several menu levels. The first level
contains the main menus. These are effective for all sources of
parameter inputs (PMU, OP1S, DriveMonitor, field bus interfaces).
The main menus are selected in parameter P60 Menu Selection.
Examples:
P060 = 0 "User parameters" menu selected
P060 = 1 "Parameter menu" selected
...
P060 = 8 "Power section definition" menu selected
Menu levels 2 and 3 enable the parameter set to be more extensively
structured. They are used for parameterizing the units with the OP1S
operator control panel.
P060 Menu Description
0 User parameters • Freely configurable menu
1 Parameter menu • Contains complete parameter set
• More extensive structure of the functions achieved by using
an OP1S operator control panel
2 Fixed settings • Used to perform a parameter reset to a factory or user setting
3
Quick
parameterization
• Used for quick parameterization with parameter modules
• When selected, the unit switches to status 5 "Drive setting"
4 Board configuration • Used for configuring the optional boards
• When selected, the unit switches to status 4 "Board
configuration"
5 Drive setting
• Used for detailed parameterization of important motor,
encoder and control data
• When selected, the unit switches to status 5 "Drive setting"
6 Download
• Used to download parameters from an OP1S, a PC or an
automation unit
• When selected, the unit switches to status 21 "Download"
7 Upread/free access
• Contains the complete parameter set and is used for free
access to all parameters without being restricted by further
menus
• Enables all parameters to be upread/upload by an OP1S, PC
or automation unit
8
Power section
definition
• Used to define the power section (only necessary for units of
the Compact and chassis type)
• When selected, the unit switches to status 0 "Power section
definition"
Table 5-1 Main menus
Menu levels
Main menus
