Parameter
Description Data Read/write
n639
Table Info
2639
This parameter passes on the table distribution to the
parameter ranges.
In the table configuration (U615 = 4), there are max. 8
tables with a total of 400 points covering the areas
from parameter XXXX in the odd-numbered indices
to parameter XXXX in the even-numbered indices
in the format:
PMU display: X X X X
T H Z E
H : 1 = U630
: 2 = U631
: 3 = U632
: 4 = U633
: 5 = U640
: 6 = U641
: 7 = U642
: 8 = U643
Z/E : 1...50 Index of the interpolation point
INDEX 1:
Table 1
The table begins....in Parameter(H), Index (Z/E)
INDEX 2:
Table 1
The table ends....in Parameter(H), Index (Z/E)
INDEX 3:
Table 2
The table begins....in Parameter(H), Index (Z/E)
INDEX 4:
Table 2
The table ends....in Parameter(H), Index (Z/E)
INDEX 5:
Table 3
The table begins....in Parameter(H), Index (Z/E)
INDEX 6:
Table 3
The table ends....in Parameter(H), Index (Z/E)
etc.
Dec.Plc.: 0
Unit: -
Indices: 16
Type: O2
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
U640*
Tab X101-X150
2640
This parameter is used to input x-coordinates 101 to 150
of the table
Function diagram [839.4]
index1: 0
Min: 0
Max:
2147483647
Unit: -
Indices: 50
Type: I4
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U641*
Tab X151-X200
2641
This parameter is used to input x-coordinates 151 to 200
of the table
Function diagram [839.4]
index1: 0
Min: 0
Max:
2147483647
Unit: -
Indices: 50
Type: I4
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
209
