Parameter
Description Data Read/write
U642*
Tab X301-X350
2642
This parameter is used to input x-coordinates 301 to 350
of the table
Function diagram [839.4]
index1: 0
Min: 0
Max:
2147483647
Unit: -
Indices: 50
Type: I4
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U643*
Tab X351-X400
2643
This parameter is used to input x-coordinates 351 to 400
of the table
Function diagram [839.4]
index1: 0
Min: 0
Max:
2147483647
Unit: -
Indices: 50
Type: I4
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
n644
Vis Act TabNo
2644
The parameter shows the table number currently
selected. Possible display values 1...8
Constituted by the binary status of U650.1..3 table
selection switch
Dec.Plc.: 0
Unit: -
Indices: -
Type: O2
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
U645*
Tab Y101-Y150
2645
This parameter is used to input y-coordinates 101 to 150
of the table
Function diagram [839.4]
index1: 0
Min: -
2147483648
Max:
2147483647
Unit: -
Indices: 50
Type: I4
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U646*
Tab Y151-Y200
2646
This parameter is used to input y-coordinates 151 to 200
of the table
Function diagram [839.4]
index1: 0
Min: -
2147483648
Max:
2147483647
Unit: -
Indices: 50
Type: I4
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U647*
Tab Y301-Y350
2647
This parameter is used to input y-coordinates 301 to 350
of the table
Function diagram [839.4]
index1: 0
Min: -
2147483648
Max:
2147483647
Unit: -
Indices: 50
Type: I4
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U648*
Tab Y351-Y400
2648
This parameter is used to input y-coordinates 351 to 400
of the table
Function diagram [839.4]
index1: 0
Min: -
2147483648
Max:
2147483647
Unit: -
Indices: 50
Type: I4
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U649*
Round Mode CU
2649
Mode for rounding the Catch Up
0 = Rounding not active on sudden reduction of the input
value during ramp up.
1 = Rounding always active. Harmonics may occur in the
event of sudden reduction of the input value.
Init: 0
Min: 0
Max: 1
Unit: -
Indices: -
Type: O2
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
