Parameter
Description Data Read/write
U650*
S.SelTable
2650
[TABLE_NO]
The parameter defines the binector for selecting the table.
Table configuration 0 => 1
Table configuration 1 => 1...2
Table configuration 2 => 1...4
Table configuration 3 => 1...8
Table configuration 4 => 1...8
Depending on the configuration, only the appropriate bits
(according to the binary code) are evaluated.
Exception:
In the case of configuration 0, table 1 is always active.
Function diagram [839.7]
index1: 0
Unit: -
Indices: 3
Type: L2 ,B
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U651*
Scale Y-Axis Fix
2651
Parameterizable fixed values for scaling the Y-axis of the
table.
The scaling of the Y-axis means that the output value of
the table (Y-axis) is multiplied by a factor. The factor is
made up of a numerator (U651.1) and a denominator
(U652.2).
Function diagram [839.5]
index1: 1
Min: -32767
Max: 32767
Unit: -
Indices: 2
Type: I2
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U652*
S.Scale Y-Axis
2652
The parameter defines the connectors from which the
numerator and denominator of the scaling factor for the Y-
axis of the table are to be read.
Index 1: Numerator
Index 2: Denominator
Function diagram [839.6]
index1: 808
Unit: -
Indices: 2
Type: L2 ,K
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
n653
TG SpeedSetpt
2653
This parameter shows the speed setpoints of
synchronism in [%].
Index 1:
Speed setpoint at output.
Function diagram [836.7]
Index 2:
Speed setpoint according to displacement angle and
catch-up.
Function diagram [836.4]
Index 3:
Speed setpoint according to 1:1 function, gear or cam.
Function diagram [835.7]
Index 4:
Speed setpoint according to continuous mode, start
mode, stop mode, or catch-up.
Function diagram [834.7]
Index 5:
Speed setpoint from master setpoint source.
Function diagram [834.5]
Dec.Plc.: 3
Unit: %
Indices: 5
Type: I4
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
n654
BoeGl_Gear.Fact.
2654
Display parameter for current gear factor Dec.Plc.: 0
Unit: -
Indices: 2
Type: I2
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
211
