Parameter
Description Data Read/write
n655
TG Pos Setpoint
2655
This parameter shows the position setpoints of
synchronism in [LU].
Index 1:
Position setpoints at output;
Function diagram [836.7]
Index 2:
Position setpoints according to displacement angle and
catch-up.
Function diagram [836.4]
Index 3:
Position setpoints according to 1:1 function, gear, or cam.
Function diagram [835.7]
Index 4:
Position setpoints according to continuous mode, start
mode, stop mode, or catch-up.
Function diagram [834.7]
Index 5:
Position setpoints from master setpoint source.
Function diagram [835.2]
Dec.Plc.: 0
Unit: -
Indices: 5
Type: I4
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
U656*
S.OperModeSync
2656
The parameter defines the source of the binectors for
changeover of the operating mode [OPERATION] of
synchronism. The mode is selected by two binectors
which are coded as follows:
U656.02 | U656.01
0 0 = Continuous operation
0 1 = Engaging action
1 0 = Disengaging action
1 1 = Disengaging action
Function diagram [834.5]
index1: 804
Unit: -
Indices: 2
Type: L2 ,B
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U657*
S.FuncSync
2657
The parameter defines the source for changeover of the
snychronism function [FUNCTION]. The function is
selected by two binectors which are coded as follows:
U657.02 | U657.01
0 0 = Angular synchronism function
0 1 = Electronic gearbox function
1 0 = Cam function
1 1 = Cam function
Function diagram [836.3]
index1: 806
Unit: -
Indices: 2
Type: L2 ,B
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
n658
Curr Mode Sync
2658
The parameter shows the active operating mode
[OPERATION] of synchronism. This is coded as follows:
O = Continuous operation
1 = Engaging action
2 = Disengaging action
Function diagram [834.6]
Dec.Plc.: 0
Unit: -
Indices: -
Type: O2
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
n659
Curr Func Sync
2659
The parameter shows the active function [FUNCTION] of
synchronism. This is coded as follows:
0 = Synchronism 1:1
1 = Gear function
2 = Table function
Function diagram [836.7]
Dec.Plc.: 0
Unit: -
Indices: -
Type: O2
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
212
Siemens AG 6SE7087-6QX70 (Edition AL)
SIMOVERT MASTERDRIVES Compendium Motion Control
