Parameter
Description Data Read/write
U665*
S.ActPos PosCo
2665
The parameter defines the source for the actual position
for position correction. Description see U662.
Function diagram [836.4]
Init: 0
Unit: -
Indices: -
Type: L2 ,K
,K
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U666*
S.StartPosCorr
2666
The parameter defines the source binector for starting
position correction. Position correction is started with a
positive edge.
Function diagram [836.4]
Init: 0
Unit: -
Indices: -
Type: L2 ,B
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U667*
PosCorrSpd
2667
The measured position difference is reduced at this speed
after position correction has started. The correction speed
is indicated in 1000 LU increments/minute.
Function diagram [836.5]
Init: 0
Min: 0
Max:
2147483647
Unit: -
Indices: -
Type: I4
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
n668
Status Table
2668
Status of the last checked table:
PMU display: X X X X
T H Z E
Z/E : 1...50 Index of the last error-free support value
H : 1 = U630 error
: 2 = U631 error
: 3 = U640 error
: 4 = U641 error
: 5 = U632 error
: 6 = U633 error
: 7 = U642 error
: 8 = U643 error
T : 0 = no error
1 = Number of support points = 0
2 = Support value > table width
3 = Ascending order of support values (x-axis)
violated
Dec.Plc.: 0
Unit: -
Indices: 8
Type: O2
Menus:
- Parameter menu
- Upread/free access
U669*
TG ReserveCon1
2669
Reserved for future functions index1: 0
Unit: -
Indices: 2
Type: L2 ,K
,K
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U670*
Mod rel. Offset
2670
U823.01 (0)
0 = Displacement is processed as absolute
1 = Displacement is processed with residual-displacement
evaluation.
U823.02 (1)
0 = Shortest path
1 = As specified (new value > old value => pos. direction)
Init: 0
Min: 0
Max: 1
Unit: -
Indices: -
Type: O2
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
214
