Parameter
Description Data Read/write
U710*
S.PosCntrSig
2710
Source for the control bits of positioning
Index1: [TGL_ I] Toggle bit input (MDI block change on
the fly)
Index2:[RIE] Read-in Enable
Index3:[STA] Start (Start / Stop positioning motion)
Index4:[CRD] Clear Remaining Distance
Index5: [ACK_ M] Acknowledge M function
Index6:[FUM] Follow-Up Mode; s_set:=s_act)
Index7: [RST] Reset Technology
Index8:[SIST] Single Step
Index9-16:MDI/Prog No. BitNo. (MDI number for MDI)
(Program number for automatic mode)
Index9:MDI/Prog No. Bit0
Index10:MDI/Prog No. Bit1
Index11:MDI/Prog No. Bit2
Index12:MDI/Prog No. Bit3
Index13:MDI/Prog No. Bit4
Index14:MDI/Prog No. Bit5
Index15:MDI/Prog No. Bit6
Index16:MDI/Prog No. Bit7
Index 17-24 OVERRIDE BitNo. Speed Override 0...255
Index17:Override Bit0
Index18:Override Bit1
Index19:Override Bit2
Index20:Override Bit3
Index21:Override Bit4
Index22:Override Bit5
Index23:Override Bit6
Index24:Override Bit7
Index25:[BLSK] Skip block:
Index26:[J_ BWD] Jog backwards
Index27:[F_ S] Fast / Slow for setup/referencing
Index28:[J_ FWD] Jog fowards
Index29-32:MODE_ IN operating mode pre-selection (can
only be changed at standstill)
Index29:Mode Bit0
Index30:Mode Bit1
Index31:Mode Bit2
Index32:Mode Bit3
index1: 0
Unit: -
Indices: 32
Type: L2 ,B
Menus:
- Parameter menu
+ Technology
+ Positioning
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U711*
CharacteristicTP
2711
[FD784b] Taper tension
Characteristic
0 = Reduction in the infinite
Lowering of the tension setpoint U717.4 is achieved only
upon an infinitely large diameter. Indication of the
maximum diameter U714.6 is not relevant.
1 = Reduction upon maximum diameter
Lowering of the tension setpoint U717.4 is achieved
exactly upon maximum diameter U714.6 and is lowered
further in the case of larger diameter values.
Init: 1
Min: 0
Max: 1
Unit: -
Indices: -
Type: O2
Menus:
- Parameter menu
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U712*
MatThickD
2712
[FD784b] Diameter calculator
Material thickness
The material thickness is used for the plausibility check. It
is entered in the same unit as the diameter (e.g. 1LU =
0.1mm).
If the material thickness is entered as zero, the plausibility
check is switched off.
Init: 0,000
Min: 0,000
Max: 65,535
Unit: -
Indices: -
Type: O2
Menus:
- Parameter menu
+ Free blocks
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
