Parameter
Description Data Read/write
U705*
ConfigDEC
2705
[FP842] Register decoupling
Index 1: Register decoupling
Operating mode
0 = Circumferential register
1 = Register rollers
Index 2: Register decoupling
Characteristic
0 = normal
index1: 0
Min: 0
Max: 1
Unit: -
Indices: 2
Type: O2
Menus:
- Parameter menu
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
n706
D.actD[LU]
2706
[FD784b] Diameter calculator
Visualization parameter for diameter actual value in LU
Dec.Plc.: 0
Unit: -
Indices: -
Type: O2
Menus:
- Parameter menu
+ Free blocks
- Upread/free access
U707*
n.NormD
2707
[FD784b] Diameter calculator
Normalization of the winding speed for the plausibility
check
The value indicates which absolute speed of the winding
shaft is set if 100% are present at input U718.2.
If the motor encoder KK91 is used here the value in P353
divided by the gear ratio has to be set.
If zero is specified the plausibility check is switched off.
Example:
Motor speed/winding speed gear ratio = 3/1
P353.1 = 3000 rpm
P353.2 = 0
Value to be set at U707 = 1000 rpm
Init: 0
Min: 0
Max: 65535
Unit: 1/min
Indices: -
Type: O2
Menus:
- Parameter menu
+ Free blocks
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U708
Override.Fixed
2708
Parameter for entering the fixed override
In function diagram 809.1
Init: 100
Min: 0
Max: 255
Unit: -
Indices: -
Type: O2
Menus:
- Parameter menu
+ Technology
+ Positioning
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U709*
S.Override P
2709
The parameter defines the source for override for
positioning. Override influences the traversing speed
during positioning. If the parameter value is 0, the override
is used by binectors U710.16 to U710.23.
Init: 859
Unit: -
Indices: -
Type: L2 ,K
Menus:
- Parameter menu
+ Technology
+ Positioning
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
220
Siemens AG 6SE7087-6QX70 (Edition AL)
SIMOVERT MASTERDRIVES Compendium Motion Control
