Parameter
Description Data Read/write
U767
AutomaticRecord
2767
The automatic record stored in the EEPROM is displayed
on parameters.
The automatic record consists of the following data:
1. Program number / continuation number / record number
2. Validity bits of functions or values
3. 1...4 G-function
4. Position
5. Speed
6. 1...3 M-function / D-number
index1: 0
Min: -
2147483647
Max:
2147483647
Unit: -
Indices: 6
Type: I4
Menus:
- Parameter menu
+ Technology
+ Positioning
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U768
AutomaticRecord
2768
The automatic record stored in the EEPROM is displayed
on parameters.
The automatic record consists of the following data:
1. Program number / continuation number / record number
2. Validity bits of functions or values
3. 1...4 G-function
4. Position
5. Speed
6. 1...3 M-function / D-number
index1: 0
Min: -
2147483647
Max:
2147483647
Unit: -
Indices: 6
Type: I4
Menus:
- Parameter menu
+ Technology
+ Positioning
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U769
AutomaticRecord
2769
The automatic record stored in the EEPROM is displayed
on parameters.
The automatic record consists of the following data:
1. Program number / continuation number / record number
2. Validity bits of functions or values
3. 1...4 G-function
4. Position
5. Speed
6. 1...3 M-function / D-number
index1: 0
Min: -
2147483647
Max:
2147483647
Unit: -
Indices: 6
Type: I4
Menus:
- Parameter menu
+ Technology
+ Positioning
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U789*
S.Multiplexer 2
2789
Source for the binectors of the multiplexer with 8
channels:
Index 1 : Signal selection Bit 0
Index 2 : Signal selection Bit 1
Index 3 : Signal selection Bit 2
Index 4 : Enable signal selection
index1: 0
Unit: -
Indices: 4
Type: L2 ,B
Menus:
- Parameter menu
+ Free blocks
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U790*
S.Multiplexer 2
2790
The parameter defines the connector inputs of the
multiplexer with 8 channels:
Index 1 : Input 1
to
Index 8 : Input 8
index1: 0
Unit: -
Indices: 8
Type: L2 ,K
,K
Menus:
- Parameter menu
+ Free blocks
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U791*
S.Multiplexer 3
2791
Source for the binectors of the multiplexer with 8
channels:
Index 1 : Signal selection Bit 0
Index 2 : Signal selection Bit 1
Index 3 : Signal selection Bit 2
Index 4 : Enable signal selection
index1: 0
Unit: -
Indices: 4
Type: L2 ,B
Menus:
- Parameter menu
+ Free blocks
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U792*
S.Multiplexer 3
2792
The parameter defines the connector inputs of the
multiplexer with 8 channels:
Index 1 : Input 1
to
Index 8 : Input 8
index1: 0
Unit: -
Indices: 8
Type: L2 ,K
,K
Menus:
- Parameter menu
+ Free blocks
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
