Siemens simovert masterdrives

Parameter
Description Data Read/write
U825*
Offset Corr Par
2825
Index 1:
Acceleration of displacement angle correction
[1000*LU/s^2]
Index 2:
Speed of displacement angle correction
[1000*LU/min]
Index 3:
Rated speed referred to by the output speed in percent
(KK832)
[1000*LU/min]
Index 4:
Here the adjusting speed [1000 LU/min] is specified for
manual adjustment via the binectors U822.3 (+) and
U822.4(-).
Index 5:
Acceleration of the adjustments for ramp-up [1000*LU/s^2]
Index 6:
Acceleration of the adjustments for ramp-down
[1000*LU/s^2]
In function diagram 794
index1: 0,00
Min: 0,00
Max:
20000000,00
Unit: -
Indices: 6
Type: O4
Menus:
- Parameter menu
+ Free blocks
- Upread/free access
Changeable in:
- Ready to switch on
n826
VisPar Displ Act
2826
Visualization parameter additive offset angle
[in function diagram 794]
Index 1: Remaining offset to add (KK833)
Index 2: Current offset (KK834)
Index 3: Output total offset (KK835)
Dec.Plc.: 0
Unit: -
Indices: 3
Type: I4
Menus:
- Parameter menu
+ Free blocks
+ Technology
+ Synchronism
- Upread/free access
U827*
Set_DispAngle
2827
With rising edge at the input, the current displacement is
set to the setting value of the connector U678.2 (setting
input).
Init: 0
Unit: -
Indices: -
Type: L2 ,B
Menus:
- Parameter menu
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U828*
S.DisplAdd
2828
Input of the modulo displacement adder
[Function diagram 794a]
index1: 0
Unit: -
Indices: 4
Type: L2 ,K
,K
Menus:
- Parameter menu
+ Free blocks
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
n829
VisPar DisAddMod
2829
Visualization parameter (KK 836)
Output of displacement adder with limitation to ACL [LU]
32 bit
[Function diagram 794a]
Dec.Plc.: 0
Unit: -
Indices: -
Type: I4
Menus:
- Parameter menu
+ Free blocks
- Upread/free access
U830*
AZL DisplaceAdd
2830
Axis cycle length for displacement adder
[Function diagram 794a]
Init: 4096
Min: 0
Max:
2147483647
Unit: -
Indices: -
Type: O4
Menus:
- Parameter menu
+ Free blocks
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U831*
S.DisplAdd_2
2831
Input of modulo displacement adder 2
[Function diagram 794a]
index1: 0
Unit: -
Indices: 4
Type: L2 ,K
,K
Menus:
- Parameter menu
+ Free blocks
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
237
Siemens AG 6SE7087-6QX70 (Edition AL)
SIMOVERT MASTERDRIVES Compendium Motion Control
